2007 Lucerne CXL ABS problems

[OG Style]

I trying to help fix a car with a abs error and I believe it is a wheel speed sensor. Does anyone know what the resistance should be on the sensors and if there is a place under the hood to test all of them?

Thank you



[polarzak]



[OG Style]

View attachment 11635

Thanks. I'm not sure what this is. I'm not getting any error codes using my obd scanner. I only have a cheap scanner.



[polarzak]

You were asking what the resistance was on the sensors.



[OG Style]

I don't understand the chart. I thought the c0040, c0045 and c0035 were trouble codes.



[OG Style]

I checked the resistance on the front wheels with them disconnect. I got about 1.2k ohms on one and the other one was reading around 60k ohms and it kept climbing.



[MelsRegal]

you have to test each one individually



[MelsRegal]

980 to 2,350 ohms is what I found as an acceptable resistance range. The 60K reading is a defective sensor.



[OG Style]

Is there a location under the hood where I can check them all? It's hard to get to the rear sensors with the wheel on. Thank you



[MelsRegal]

no they are tested at the wheel sensor connector at each wheel



[OG Style]

I'll do that. Thank you
